Inductive Proximity Sensors

Crane high-performance Pressure Sensors are specifically designed to satisfy the requirements of aerospace and other severe applications. Utilizing Silicon-on-Sapphire sensing technology, Crane pressure sensors provide extremely high-accuracy (0.01% full-scale) and excellent long term stability for reliable pressure sensing in severe environmental conditions.

Well suited for demanding measurement and control applications, these sensors can be configured with a variety of outputs, and are compatible with harsh media and an ability to support pressures up to 5,000 psi.

Versatile, modular and adaptable in order to satisfy the most demanding customer requirements.

proximity sensor brochure cover

Titanium Proximity Sensors

The new proximity sensor for the Boeing 737 offers an enhanced titanium design that greatly improves the sensor reliability in the most harsh sensor locations.



All-metal Passive Sensors

Click on the Part Number to see the Data Sheet, then press your Browser's Back button to return to this page.

Physical Configuration Senses... Nominal Actuation
Point		 Termination Systems
Used In		 Part Number
LG DR FC T/R
Rectangular Ferrous steel 0.138" (3.51) Connector x x x x 8-933
Rectangular Ferrous steel 0.240" (6.10) Pigtail x x x x 80-008
5/8" (15.88)
Cylindrical barrel		 Ferrous steel 0.085" (2.16) Pigtail x x x x 8-642
5/8" (15.88)
Cylindrical barrel		 Ferrous steel 0.082" (2.08) Connector x x x x 8-695
3/4" (19.05)
Cylindrical barrel		 Ferrous steel 0.104" (2.64) Pigtail x x x x 8-873

(mm: millimeters); LG: Landing Gear; DR: Doors; FC: Flight Controls; T/R: Thrust Reverser



Hermetic Active Sensors (one-piece switches)

Click on the Part Number to see the Data Sheet, then press your Browser's Back button to return to this page.

Cylindrical Barrel Diameter Senses... Nominal Actuation
Point		 Electrical Output Termination Systems
Used In		 Part Number
LG DR FC T/R
5/8" (15.88) All metals 0.100" (2.54) 250 ma sinking Connector x x x x 8-527
5/8" (15.88) All metals 0.100" (2.54) 250 ma sinking Connector x x x x 8-552
5/8" (15.88) All metals 0.100" (2.54) 250 ma sinking Pigtail   x x x 8-644
0.787" All metals 0.118" (3) 500 ma sinking Connector x x     80-133
5/8" (15.88) Ferrous steel 0.100" (2.54) 250 ma sinking Connector x x x x 80-057
3/4" (19.05) Ferrous steel 0.100" (2.54) 250 ma sinking Pigtail x x   x 80-116
3/4" (19.05) Ferrous steel 0.225" (5.72) 500 ma sourcing Connector x x x x 8-571
3/4" (19.05) Ferrous steel 0.175" (4.45) 500 ma sourcing, dual output Connector x x x x 8-860
Right-angle 3/4" (19.05) Ferrous steel 0.090" (22.86) 250 ma sinking Connector x x x x 8-827
Right-angle 3/4" (19.05) Ferrous steel 0.175" (4.45) 500 ma sourcing, dual output Connector x x x x 8-884
7/8" (22.23) high-pressure compatible Ferrous steel 0.080" (2.03) 750 ma sourcing Connector x       8-545
7/8" (22.23) high-pressure compatible Ferrous steel 0.050" (1.27) 500 ma sinking Connector x       8-828

(mm: millimeters); LG: Landing Gear; DR: Doors; FC: Flight Controls; T/R: Thrust Reverser



Environmentally Sealed Active Sensors (one-piece switches)

Click on the Part Number to see the Data Sheet, then press your Browser's Back button to return to this page.

Cylindrical Barrel Diameter Senses... Nominal Actuation
Point		 Electrical Output Termination Systems
Used In		 Part Number
LG DR FC T/R
15/32" (11.91) All metals 0.100" (2.54) 250 ma sinking Pigtail   x     8-405
0.50" (12.70) All metals 0.080" (2.03) 500 ma sinking Connector   x     72A14
0.64" (16.26) All metals 0.138" (3.51) 500 ma sourcing or sinking, dual output Connector x x     72A04

(mm: millimeters); LG: Landing Gear; DR: Doors; FC: Flight Controls; T/R: Thrust Reverser
