Electrical Power Solutions: Interpoint® MSA Series™ and MGA Series™
Electrical Power Solutions: Interpoint® MSA Series™ and MGA Series™
Product Type: DC-DC Converters
Application: High Reliability
Application: High Reliability
FEATURES
- Small size, 1.14 in2 (7.31 cm2) - MSA
- Surface mount package - MGA
- -55° to +125°C operation
- 16 to 40 volt input
- 50 volts for 50 ms transient protection
- Fully isolated
- Fixed high frequency switching
- Inhibit function
- Indefinite short circuit protection
- Up to 76% efficiency
- Soft-start function limits inrush current during start-up
| Model | Nominal Input Voltage | Input Voltage Range | Number of Outputs | Output Voltage | Total Output Power (W) | Auxiliary Output Voltage | Auxiliary Output Power | Typical Efficiency |
|---|---|---|---|---|---|---|---|---|
| Model: MSA2805S | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 1 | Output Voltage: 5 | Total Output Power (W): 5 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 71 |
| Model: MSA285R2S | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 1 | Output Voltage: 5.2 | Total Output Power (W): 5 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 71 |
| Model: MSA2812S | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 1 | Output Voltage: 12 | Total Output Power (W): 5 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 76 |
| Model: MSA2815S | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 1 | Output Voltage: 15 | Total Output Power (W): 5 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 76 |
| Model: MSA2805D | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 2 | Output Voltage: 5 | Total Output Power (W): 5 | Auxiliary Output Voltage: -5 | Auxiliary Output Power: 4 | Typical Efficiency: 72 |
| Model: MSA2812D | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 2 | Output Voltage: 12 | Total Output Power (W): 5 | Auxiliary Output Voltage: -12 | Auxiliary Output Power: 4 | Typical Efficiency: 75 |
| Model: MSA2815D | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 2 | Output Voltage: 15 | Total Output Power (W): 5 | Auxiliary Output Voltage: -15 | Auxiliary Output Power: 4 | Typical Efficiency: 75 |
