MOR Series™ – 16 to 40 Volt Input – 120 Watts
Application: High Reliability
The MOR Series is available with Class H SMD numbers, up to 87% typical efficiency and 16 to 40 volt input in single, dual or triple output models.
Parallel operation with current share, up to 5 units (540 watts)
Output trim of 60% to 110% provides outputs from 2 to 33 VDC
- Operating temperature -55° to +125°C
- Compliant up to Class H, see datasheet for SMD numbers
- Input voltage 16 to 40 VDC
- Transient protection 50 V for 120 ms
- Fully isolated, magnetic feedback
- Fixed high frequency switching
- Remote sense
- Inhibit function
- Synchronization input and output
- Indefinite short circuit protection
- High power density with up to 87% efficiency
- Case size: 3.005 × 1.505 × 0.400 inches (76.33 × 38.23 × 10.16 mm)
- Tabbed case and lead options available
| Model | Nominal Input Voltage | Input Voltage Range | Number of Outputs | Output Voltage | Total Output Power (W) | Auxiliary Output Voltage | Auxiliary Output Power | Typical Efficiency |
|---|---|---|---|---|---|---|---|---|
| Model: MOR283R3S | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 1 | Output Voltage: 3.3 | Total Output Power (W): 66 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 78 |
| Model: MOR2805S | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 1 | Output Voltage: 5 | Total Output Power (W): 100 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 81 |
| Model: MOR286R3S | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 1 | Output Voltage: 6.3 | Total Output Power (W): 100 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 83 |
| Model: MOR289R5S | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 1 | Output Voltage: 9.5 | Total Output Power (W): 105 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 84 |
| Model: MOR2812S | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 1 | Output Voltage: 12 | Total Output Power (W): 110 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 86 |
| Model: MOR283R3D | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 2 | Output Voltage: 3.3 | Total Output Power (W): 66 | Auxiliary Output Voltage: -3.3 | Auxiliary Output Power: 476 | Typical Efficiency: 77 |
| Model: MOR2805D | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 2 | Output Voltage: 5 | Total Output Power (W): 100 | Auxiliary Output Voltage: -5 | Auxiliary Output Power: 70 | Typical Efficiency: 81 |
| Model: MOR286R3D | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 2 | Output Voltage: 6.3 | Total Output Power (W): 100 | Auxiliary Output Voltage: -6.3 | Auxiliary Output Power: 70 | Typical Efficiency: 83 |
| Model: MOR289R5D | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 2 | Output Voltage: 9.5 | Total Output Power (W): 105 | Auxiliary Output Voltage: -9.5 | Auxiliary Output Power: 73.5 | Typical Efficiency: 84 |
| Model: MOR2812D | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 2 | Output Voltage: 12 | Total Output Power (W): 110 | Auxiliary Output Voltage: -12 | Auxiliary Output Power: 77 | Typical Efficiency: 86 |
| Model: MOR2815D | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 2 | Output Voltage: 15 | Total Output Power (W): 120 | Auxiliary Output Voltage: -15 | Auxiliary Output Power: 84 | Typical Efficiency: 87 |
| Model: MOR2815S | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 1 | Output Voltage: 15 | Total Output Power (W): 120 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 87 |
