MFK Series™ – 16 to 50 Volt Input – 25 Watts
Application: High Reliability
The MFK Series now meets MIL-STD-704A 80 volt transient spec. The MFK is available with Class H SMD numbers, an input range of 16-50 volts, 13 different output models, up to 25 watts of output power and 87% efficiency. Standard and ES screening also available.
Up to 87% efficiency, up to 42 W/in3
16 to 50 volt input
- 1.8, 2.5, 3.3, 5, 5.2, 5.7, 12, 15 and 28 volt single outputs
- Compliant up to Class H, see datasheet for SMD numbers
- ±5, ±7, ±12 and ±15 volt dual outputs
- Undervoltage lockout
- -55°C to +125°C operation
- Fully isolated
- Magnetic feedback
- Fixed frequency, 500 kHz typical
- 80 V transient protection per MIL-STD-704A
- Inhibit and sync function
- Output short circuit protection
- Inhibit and sync function
- Case size:
- 1.460 × 1.130 × 0.360 inches (37.08 × 28.70 × 9.14 mm)
- Flanged 2.005 × 1.130 × 0.360 inches (50.93 × 28.70 × 9.14 mm)
| Model | Nominal Input Voltage | Input Voltage Range | Number of Outputs | Output Voltage | Total Output Power (W) | Auxiliary Output Voltage | Auxiliary Output Power | Typical Efficiency |
|---|---|---|---|---|---|---|---|---|
| Model: MFK281R8S | Nominal Input Voltage: 28 | Input Voltage Range: 16-50 | Number of Outputs: 1 | Output Voltage: 1.8 | Total Output Power (W): 10 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 72 |
| Model: MFK282R5S | Nominal Input Voltage: 28 | Input Voltage Range: 16 | Number of Outputs: 1 | Output Voltage: 2.5 | Total Output Power (W): 12.5 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 76 |
| Model: MFK283R3S | Nominal Input Voltage: 28 | Input Voltage Range: 16-50 | Number of Outputs: 1 | Output Voltage: 3.3 | Total Output Power (W): 15 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 79 |
| Model: MFK2805S | Nominal Input Voltage: 28 | Input Voltage Range: 16-50 | Number of Outputs: 1 | Output Voltage: 5 | Total Output Power (W): 20 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 82 |
| Model: MFK285R2S | Nominal Input Voltage: 28 | Input Voltage Range: 16-50 | Number of Outputs: 1 | Output Voltage: 5.2 | Total Output Power (W): 20.8 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 82 |
| Model: MFK285R7S | Nominal Input Voltage: 28 | Input Voltage Range: 16-50 | Number of Outputs: 1 | Output Voltage: 5.7 | Total Output Power (W): 22.8 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 82 |
| Model: MFK2812S | Nominal Input Voltage: 28 | Input Voltage Range: 16-50 | Number of Outputs: 1 | Output Voltage: 12 | Total Output Power (W): 25 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 86 |
| Model: MFK2815S | Nominal Input Voltage: 28 | Input Voltage Range: 16-50 | Number of Outputs: 1 | Output Voltage: 15 | Total Output Power (W): 25 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 87 |
| Model: MFK2828S | Nominal Input Voltage: 28 | Input Voltage Range: 16-50 | Number of Outputs: 1 | Output Voltage: 28 | Total Output Power (W): 25 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 84 |
| Model: MFK2805D | Nominal Input Voltage: 28 | Input Voltage Range: 16-50 | Number of Outputs: 2 | Output Voltage: 5 | Total Output Power (W): 20 | Auxiliary Output Voltage: -5 | Auxiliary Output Power: 14 | Typical Efficiency: 81 |
| Model: MFK2807D | Nominal Input Voltage: 28 | Input Voltage Range: 16-50 | Number of Outputs: 2 | Output Voltage: 7 | Total Output Power (W): 21 | Auxiliary Output Voltage: -7 | Auxiliary Output Power: 14.7 | Typical Efficiency: 83 |
| Model: MFK2812D | Nominal Input Voltage: 28 | Input Voltage Range: 16-50 | Number of Outputs: 2 | Output Voltage: 12 | Total Output Power (W): 21 | Auxiliary Output Voltage: -12 | Auxiliary Output Power: 17.5 | Typical Efficiency: 85 |
| Model: MFK2815D | Nominal Input Voltage: 28 | Input Voltage Range: 16-50 | Number of Outputs: 2 | Output Voltage: 15 | Total Output Power (W): 15 | Auxiliary Output Voltage: -15 | Auxiliary Output Power: 17.5 | Typical Efficiency: 86 |
