FMCE-0828™ – 0 to 50 Volts In – 8 Amps
Application: High Reliability
The FMCE-0828 EMI filters reduce the reflected input ripple current of high frequency MOR, MFL, MFX, MWR, MTR, MFK, MHV and MHF+ Series Interpoint® DC-DC converters the bringing them into compliance with Military Standard 461C CE03/CS01 and 461D, E and F CE102/CS101 levels of conducted emissions of converters. One filter can be used with multiple converters up to the rated output current of the filter.
Attenuation to 50 dB minimum at 500 kHz
- • Operating temperature -55° to +125°C
• Nominal 28 V input, -0.5 to 50 V operation
• Transient rating -0.5 to 80 V for 1 second
• Up to 8 A throughput current -0.5 to 50 Vin
• Compliant to
— MIL-STD-461C CE03
— MIL-STD-461D, E and F CE102
— MIL-STD-461C CS01
— MIL-STD-461D, E, and F CS101
• Compatible with MIL-STD-704 A-E 28 VDC power bus
| Model | Nominal Input Voltage | Input Voltage Range |
|---|---|---|
| Model: FMCE-0828 | Nominal Input Voltage: 28 | Input Voltage Range: 0-50 |
