Electrical Power Solutions: Interpoint® MTR (50) Series™
Electrical Power Solutions: Interpoint® MTR (50) Series™
Product Type: DC-DC Converters
Application: High Reliability
Application: High Reliability
The MTR 50 is available with Class H SMD numbers,16 to 50 volt input, single or dual outputs and up to 81% typical.
Input voltage range 16 to 50 VDC
Transient protection up to 80 V per MIL-STD-704A
- Operating temperature -55°C to +125°C
- Class H SMD numbers available for all models
- Fully isolated, magnetic feedback
- Fixed high frequency switching
- Inhibit and synchronization function
- Indefinite short circuit and overload protection
- Case size:
- 2.100 × 1.115 × 0.400 inches (53.34 × 28.32 × 10.16 mm)
- Flanged 2.910 × 1.115 × 0.400 inches (73.91 × 28.32 × 10.16 mm)
| Model | Nominal Input Voltage | Input Voltage Range | Number of Outputs | Output Voltage | Total Output Power (W) | Auxiliary Output Voltage | Auxiliary Output Power | Typical Efficiency |
|---|---|---|---|---|---|---|---|---|
| Model: MTR283R3S (MTR (50) | Nominal Input Voltage: 28 | Input Voltage Range: 16-50 | Number of Outputs: 1 | Output Voltage: 3.3 | Total Output Power (W): 20 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 74 |
| Model: MTR2805S (MTR 50) | Nominal Input Voltage: 28 | Input Voltage Range: 16-50 | Number of Outputs: 1 | Output Voltage: 5 | Total Output Power (W): 25 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 77 |
| Model: MTR288R5S (MTR 50) | Nominal Input Voltage: 28 | Input Voltage Range: 16-50 | Number of Outputs: 1 | Output Voltage: 8.5 | Total Output Power (W): 25 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 81 |
| Model: MTR2812S (MTR 50) | Nominal Input Voltage: 28 | Input Voltage Range: 16-50 | Number of Outputs: 1 | Output Voltage: 12 | Total Output Power (W): 30 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 80 |
| Model: MTR2815S (MTR 50) | Nominal Input Voltage: 28 | Input Voltage Range: 16-50 | Number of Outputs: 1 | Output Voltage: 15 | Total Output Power (W): 30 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 80 |
| Model: MTR2805D (MTR 50) | Nominal Input Voltage: 28 | Input Voltage Range: 16-50 | Number of Outputs: 2 | Output Voltage: 5 | Total Output Power (W): 25 | Auxiliary Output Voltage: -5 | Auxiliary Output Power: 22.5 | Typical Efficiency: 79 |
| Model: MTR2812D (MTR 50) | Nominal Input Voltage: 28 | Input Voltage Range: 16-50 | Number of Outputs: 2 | Output Voltage: 12 | Total Output Power (W): 30 | Auxiliary Output Voltage: -12 | Auxiliary Output Power: 27 | Typical Efficiency: 80 |
| Model: MTR2815D (MTR 50) | Nominal Input Voltage: 28 | Input Voltage Range: 16-50 | Number of Outputs: 2 | Output Voltage: 15 | Total Output Power (W): 30 | Auxiliary Output Voltage: -15 | Auxiliary Output Power: 27 | Typical Efficiency: 80 |
