MTR (40) Single, Dual and Triple DC-DC Converters
Application: High Reliability
FEATURES
• No cross-regulation error in triple output models
• Operating temperature -55° to +125°C
• Input voltage range 16 to 40 volts
• Transient protection 50 Vin for 50 ms
• Fully isolated, magnetic feedback
• Fixed high frequency switching
• Inhibit and synchronization function
• Indefinite short circuit and overload protection
| Model | Nominal Input Voltage | Input Voltage Range | Number of Outputs | Output Voltage | Total Output Power (W) | Auxiliary Output Voltage | Auxiliary Output Power | Typical Efficiency |
|---|---|---|---|---|---|---|---|---|
| Model: MTR283R3S | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 1 | Output Voltage: 3.3 | Total Output Power (W): 20 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 76 |
| Model: MTR2805S | Nominal Input Voltage: 28 | Input Voltage Range: 1 | Number of Outputs: | Output Voltage: 5 | Total Output Power (W): 25 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 78 |
| Model: MTR288R5S | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 1 | Output Voltage: 8.5 | Total Output Power (W): 25 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 80 |
| Model: MTR2812S | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 1 | Output Voltage: 12 | Total Output Power (W): 30 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 83 |
| Model: MTR2815S | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 1 | Output Voltage: 15 | Total Output Power (W): 30 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 84 |
| Model: MTR2818S | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 1 | Output Voltage: 18 | Total Output Power (W): 30 | Auxiliary Output Voltage: NA | Auxiliary Output Power: NA | Typical Efficiency: 84 |
| Model: MTR2805D | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 2 | Output Voltage: 5 | Total Output Power (W): 25 | Auxiliary Output Voltage: -5 | Auxiliary Output Power: 22.5 | Typical Efficiency: 78 |
| Model: MTR2812D | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 2 | Output Voltage: 12 | Total Output Power (W): 30 | Auxiliary Output Voltage: -12 | Auxiliary Output Power: 27 | Typical Efficiency: 81 |
| Model: | Nominal Input Voltage: | Input Voltage Range: | Number of Outputs: | Output Voltage: | Total Output Power (W): | Auxiliary Output Voltage: | Auxiliary Output Power: | Typical Efficiency: |
| Model: MTR2815D | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 2 | Output Voltage: 15 | Total Output Power (W): 30 | Auxiliary Output Voltage: -15 | Auxiliary Output Power: 27 | Typical Efficiency: 83 |
| Model: MTR28512T | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 3 | Output Voltage: 5 | Total Output Power (W): 30 | Auxiliary Output Voltage: +/-12 | Auxiliary Output Power: 10 | Typical Efficiency: 75 |
| Model: MTR28515T | Nominal Input Voltage: 28 | Input Voltage Range: 16-40 | Number of Outputs: 3 | Output Voltage: 5 | Total Output Power (W): 30 | Auxiliary Output Voltage: +/-15 | Auxiliary Output Power: 10 | Typical Efficiency: 75 |
