cMOR Single and Dual DC-DC Converters
DESCRIPTION
The Interpoint® cMOR Series™ of DC-DC converters offers up to 120 watts of power in a low profile package with a 15 to 50 volt input. The cMOR converters are manufactured in our fully certified and qualified MIL-PRF-38534 Class H or class K production facility and packaged in hermetically sealed steel cases. cMOR converters are ideal for use in programs requiring high reliability, small size, and high efficiency. Full operation over the temperature range, -55°C to +105°C, makes the cMOR Series an ideal choice for military, aerospace, space, and other high reliability applications. Use Interpoint FMCE-1528 EMI filter to meet the requirements of MIL-STD-461C CE03 and MIL-STD-461D-G CE102 levels of conducted emissions.
DC-DC Converters
FEATURES
- Parallel operation with current share, up to 5 units (540 watts)
- Output flexibility, trim of 80% to 110%
- Operating temperature -55°C to +105°C
- Input voltage 15 to 50 V
- Fully isolated, magnetic feedback
- Fixed high frequency switching
- Remote sense on single output models
- Inhibit function
- Sync In and Sync Out
- Indefinite short circuit protection
- High power density with up to 90% peak efficiency
- Soft-start function limits inrush current during start-up
| Model | Nominal Input Voltage | Input Voltage Range | Number of Outputs |
|---|---|---|---|
| Model: cMOR2805D | Nominal Input Voltage: 28 | Input Voltage Range: 15 to 50 | Number of Outputs: 2 |
| Model: cMOR2805S | Nominal Input Voltage: 28 | Input Voltage Range: 15 to 50 | Number of Outputs: 1 |
| Model: cMOR2812D | Nominal Input Voltage: 28 | Input Voltage Range: 15 to 50 | Number of Outputs: 2 |
| Model: cMOR2812S | Nominal Input Voltage: 28 | Input Voltage Range: 15 to 50 | Number of Outputs: 1 |
| Model: cMOR2815D | Nominal Input Voltage: 28 | Input Voltage Range: 15 to 50 | Number of Outputs: 2 |
| Model: cMOR2815S | Nominal Input Voltage: 28 | Input Voltage Range: 15 to 50 | Number of Outputs: 1 |
| Model: cMOR2828S | Nominal Input Voltage: 28 | Input Voltage Range: 15 to 50 | Number of Outputs: 1 |
| Model: cMOR283R3S | Nominal Input Voltage: 28 | Input Voltage Range: 15 to 50 | Number of Outputs: 1 |
| Model: cMOR286R3D | Nominal Input Voltage: 28 | Input Voltage Range: 15 to 50 | Number of Outputs: 2 |
| Model: cMOR286R3S | Nominal Input Voltage: 28 | Input Voltage Range: 15 to 50 | Number of Outputs: 1 |
| Model: cMOR289R5D | Nominal Input Voltage: 28 | Input Voltage Range: 15 to 50 | Number of Outputs: 2 |
| Model: cMOR289R5S | Nominal Input Voltage: 28 | Input Voltage Range: 15 to 50 | Number of Outputs: 1 |
